构建实时终端节点 WebSocket 客户

实时 WebSocket GraphQL 订阅的客户端实现

以下顺序图和步骤显示了两者之间的实时订阅工作流 WebSocket 客户端、HTTP 客户端和Amazon AppSync.

  1. 客户建立了 WebSocket 与Amazon AppSync 实时终端节点。如果存在网络错误，则客户端应该执行抖动指数退避。有关更多信息，请参阅指数回退和抖动在Amazon建筑博客。

  2. 成功建立后 WebSocket 连接，客户端发送connection_init消息。

  3. 客户端等待connection_ack消息来自的消息Amazon AppSync. 此消息包括connectionTimeoutMs参数，这是以毫秒为单位的最长等待时间"ka"（保持连接）消息。

  4. Amazon AppSync 发送"ka"定期发送消息。客户端跟踪收到的时间"ka"消息。如果客户没有收到"ka"内部消息connectionTimeoutMs毫秒，客户端应关闭连接。

  5. 客户端通过发送 start 订阅消息来注册订阅。单个单个数 WebSocket 连接支持多个订阅，即使它们处于不同的授权模式。

  6. 客户端等待 Amazon AppSync 发送 start_ack 消息来确认订阅成功。如果出现错误，则 Amazon AppSync 返回一条 "type": "error" 消息。

  7. 客户端监听订阅事件，这些事件是在调用对应的更改之后发送的。查询和更改通常通过 https:// 发送到 Amazon AppSync GraphQL 终端节点。订阅流经过Amazon AppSync 使用安全的实时终端节点 WebSocket (wss://)。

  8. 客户端通过发送 stop 订阅消息来取消注册订阅。

  9. 取消注册所有订阅并检查没有通过 WebSocket，客户端可以断开与 WebSocket 连接.

建立 Dews Device WebSocket 连接

使用进行连接并启动成功的握手Amazon AppSync，一个 WebSocket 客户端需要以下内容：

  • 这些区域有：Amazon AppSync 实时终端节点

  • 查询字符串，了解相关信息header和payload参数

    • header：包含与 Amazon AppSync 终端节点和授权相关的信息。这是一个来自字符串化 JSON 对象的 base64 编码字符串。JSON 对象内容因授权模式而异。

    • payload：Base64 编码的字符串payload.

有了这些要求， WebSocket 客户端可以使用以下方式连接到 URL，该 URL 包含带有查询字符串的实时终端节点graphql-ws作为 WebSocket 协议。

从 GraphQL 终端节点发现 实时终端节点

Amazon AppSync GraphQL 终端节点和 Amazon AppSync 实时终端节点在协议和域方面略有不同。您可以使用检索 GraphQL 终端节点的Amazon Command Line Interface(Amazon CLI) 命令aws appsync get-graphql-api.

Amazon AppSync GraphQL 终端节点：

https://example1234567890000.appsync-api.us-east-1.amazonaws.com/graphql

Amazon AppSync 实时终端节点：

wss://example1234567890000.appsync-realtime-api.us-east-1.amazonaws.com/graphql

应用程序可以使用任何 HTTP 客户端连接到 Amazon AppSync GraphQL 终端节点 (https://) 进行查询和更改。应用程序可以连接到Amazon AppSync 实时终端节点 (wss://) 使用任何 WebSocket 订阅客户端。

使用自定义域名，您可以使用单个域与两个端点进行交互。例如，如果您配置api.example.com作为您的自定义域，您可以使用以下 URL 与 GraphQL 和实时端点进行交互：

Amazon AppSync 自定义域 GraphQL 终端节点：

https://api.example.com/graphql

Amazon AppSync 自定义域实时终端节点：

wss://api.example.com/graphql/realtime

基于 Amazon AppSync API 授权模式的标头参数格式

的格式header连接查询字符串中使用的对象因Amazon AppSync API 授权模式。对象中的 host 字段引用 Amazon AppSync GraphQL 终端节点，该终端节点用于验证连接，即使 wss:// 调用针对的是实时终端节点。要启动握手并建立授权连接，payload 应为空 JSON 对象。

API 密钥

标头内容：

  • "host": <string>: 的主机Amazon AppSync GraphQL 终端节点或您的自定义域名。

  • "x-api-key": <string>：为配置的 API 密钥Amazon AppSync API。

示例：

{
    "host":"example1234567890000.appsync-api.us-east-1.amazonaws.com",
    "x-api-key":"da2-12345678901234567890123456"
}

负载内容：

{}

请求 URL：

wss://example1234567890000.appsync-realtime-api.us-east-1.amazonaws.com/graphql?header=eyJob3N0IjoiZXhhbXBsZTEyMzQ1Njc4OTAwMDAuYXBwc3luYy1hcGkudXMtZWFzdC0xLmFtYXpvbmF3cy5jb20iLCJ4LWFtei1kYXRlIjoiMjAyMDA0MDFUMDAxMDEwWiIsIngtYXBpLWtleSI6ImRhMi16NHc0NHZoczV6Z2MzZHRqNXNranJsbGxqaSJ9&payload=e30=

Amazon Cognito 用户池和 OpenID Connect (OIDC)

标头内容：

  • "Authorization": <string>: 一个 JWT ID 令牌。标题可以使用持票人计划.

  • "host": <string>: 的主机Amazon AppSync GraphQL 终端节点或您的自定义域名。

示例：

{
    "Authorization":"eyEXAMPLEiJjbG5xb3A5eW5MK09QYXIrMTJHWEFLSXBieU5WNHhsQjEXAMPLEnM2WldvPSIsImFsZyI6IlEXAMPLEn0.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.B4EXAMPLEFNpJ6ikVp7e6DRee95V6Qi-zEE2DJH7sHOl2zxYi7f-SmEGoh2AD8emxQRYajByz-rE4Jh0QOymN2Ys-ZIkMpVBTPgu-TMWDyOHhDUmUj2OP82yeZ3wlZAtr_gM4LzjXUXmI_K2yGjuXfXTaa1mvQEBG0mQfVd7SfwXB-jcv4RYVi6j25qgow9Ew52ufurPqaK-3WAKG32KpV8J4-Wejq8t0c-yA7sb8EnB551b7TU93uKRiVVK3E55Nk5ADPoam_WYE45i3s5qVAP_-InW75NUoOCGTsS8YWMfb6ecHYJ-1j-bzA27zaT9VjctXn9byNFZmEXAMPLExw",
    "host":"example1234567890000.appsync-api.us-east-1.amazonaws.com"
}

负载内容：

{}

请求 URL：

wss://example1234567890000.appsync-realtime-api.us-east-1.amazonaws.com/graphql?header=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&payload=e30=

IAM

标头内容如下：

  • "accept": "application/json, text/javascript"：常量 <string> 参数。

  • "content-encoding": "amz-1.0"：常量 <string> 参数。

  • "content-type": "application/json; charset=UTF-8"：常量 <string> 参数。

  • "host": <string>：这是 Amazon AppSync GraphQL 终端节点的主机。-"x-amz-date": <string>：时间戳必须采用 UTC 表示，并具有以下 ISO 8601 格式：YYYMMDD'T'HHMMSS'Z'。例如，20150830T123600Z 是一个有效的时间戳。请勿在时间戳中包含毫秒。有关更多信息，请参阅处理 Signature Version 4 中的日期中的Amazon一般参考.

    • "X-Amz-Security-Token":<string>: 这些区域有：Amazon会话令牌，使用临时安全证书时必需。有关更多信息，请参阅将临时凭证用于Amazon资源中的IAM 用户指南.

    • "Authorization": <string>：签名版本 4 (SigV4) 签名信息Amazon AppSync 终端节点。有关签名过程的更多信息，请参阅。任务 4 将签名添加到 HTTP 请求中的Amazon一般参考.

Sigv4 签名 HTTP 请求包含一个规范 URL，它是附加了 /connect 的 Amazon AppSync GraphQL 终端节点。服务终端节点Amazon区域与您正在使用的区域相同Amazon AppSync API，服务名称为 “appsync”。要签名的 HTTP 请求如下所示：

{
  url: "https://example1234567890000.appsync-api.us-east-1.amazonaws.com/graphql/connect",
  data: "{}",
  method: "POST",
  headers: {
    "accept": "application/json, text/javascript",
    "content-encoding": "amz-1.0",
    "content-type": "application/json; charset=UTF-8",
  }
}

示例：

{
  "accept": "application/json, text/javascript",
  "content-encoding": "amz-1.0",
  "content-type": "application/json; charset=UTF-8",
  "host": "example1234567890000.appsync-api.us-east-1.amazonaws.com",
  "x-amz-date": "20200401T001010Z",
  "X-Amz-Security-Token": "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",
  "Authorization": "AWS4-HMAC-SHA256 Credential=XXXXXXXXXXXXXXXXXXX/20200401/us-east-1/appsync/aws4_request, SignedHeaders=accept;content-encoding;content-type;host;x-amz-date;x-amz-security-token, Signature=83EXAMPLEbcc1fe3ee69f75cd5ebbf4cb4f150e4f99cec869f149c5EXAMPLEdc"
}

负载内容：

{}

请求 URL：

wss://example1234567890000.appsync-realtime-api.us-east-1.amazonaws.com/graphql?header=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&payload=e30=

要使用自定义域签署请求，请执行以下操作：

{
  url: "https://api.example.com/graphql/connect",
  data: "{}",
  method: "POST",
  headers: {
    "accept": "application/json, text/javascript",
    "content-encoding": "amz-1.0",
    "content-type": "application/json; charset=UTF-8",
  }
}

示例：

{
  "accept": "application/json, text/javascript",
  "content-encoding": "amz-1.0",
  "content-type": "application/json; charset=UTF-8",
  "host": "api.example.com",
  "x-amz-date": "20200401T001010Z",
  "X-Amz-Security-Token": "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",
  "Authorization": "AWS4-HMAC-SHA256 Credential=XXXXXXXXXXXXXXXXXXX/20200401/us-east-1/appsync/aws4_request, SignedHeaders=accept;content-encoding;content-type;host;x-amz-date;x-amz-security-token, Signature=83EXAMPLEbcc1fe3ee69f75cd5ebbf4cb4f150e4f99cec869f149c5EXAMPLEdc"
}

负载内容：

{}

请求 URL：

wss://api.example.com/graphql?header=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&payload=e30=

注意：第一 WebSocket 连接可以有多个订阅（即使使用不同的身份验证模式）。实现此目的的一种方法是创建一个 WebSocket 连接第一个订阅，然后在取消注册最后一个订阅时关闭它。您可以通过等待几秒钟再关闭来优化此功能 WebSocket 连接，以避免在取消注册最后一个订阅之后立即订阅应用程序。对于移动应用程序示例，在从一个屏幕更改到另一个屏幕时，打开卸载event 它会停止订阅，然后开启安装中如果它启动了不同的订阅。

Lambda 授权

标头内容：

  • "Authorization": <string>: 传递的值为authorizationToken.

  • "host": <string>: 的主机Amazon AppSync GraphQL 终端节点或您的自定义域名。

示例：

{
    "Authorization":"M0UzQzM1MkQtMkI0Ni00OTZCLUI1NkQtMUM0MTQ0QjVBRTczCkI1REEzRTIxLTk5NzItNDJENi1BQjMwLTFCNjRFNzQ2NzlCNQo=",
    "host":"example1234567890000.appsync-api.us-east-1.amazonaws.com"
}

负载内容：

{}

请求 URL：

wss://example1234567890000.appsync-realtime-api.us-east-1.amazonaws.com/graphql?header=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&payload=e30=

实时 WebSocket手术

成功启动后 WebSocket 与握手Amazon AppSync，客户端必须发送后续消息才能连接到Amazon AppSync 用于不同的操作。这些消息需要以下数据：

  • type：操作的类型。

  • id：订阅的唯一标识符。我们建议为此目的使用 UUID。

  • payload：关联的有效载荷，取决于操作类型。

这些区域有：type字段是唯一的必填字段；id和payload字段是可选的。

事件序列

要成功启动、建立、注册和处理订阅请求，客户端必须逐步完成以下序列：

  1. 初始化连接 (connection_init)

  2. 连接确认 (connection_ack)

  3. 订阅注册 (start)

  4. 订阅确认 (start_ack)

  5. 处理订阅 (data)

  6. 订阅取消注册 (stop)

连接启动消息

成功握手后，客户端必须发送connection_init要开始与通信的消息Amazon AppSync实时终端节点。如果没有此步骤，将忽略所有其他消息。该消息是通过将下列 JSON 对象字符串化获得的字符串，如下所示：

{ "type": "connection_init" }

连接确认消息

发送 connection_init 消息后，客户端必须等待 connection_ack 消息。接收前发送的所有消息connection_ack被忽略。该消息具体如下：

{
  "type": "connection_ack",
  "payload": {
    // Time in milliseconds waiting for ka message before the client should terminate the WebSocket connection
    "connectionTimeoutMs": 300000
  }
}

保持活动消息

除了连接确认消息外，客户端还会定期接收保持活动消息。如果客户端在连接超时时间内没有收到保持活动状态的消息，则客户端应关闭连接。Amazon AppSync 继续发送这些消息并为注册的订阅提供服务，直到连接自动关闭（24 小时后）。保持活动状态消息是检测信号，不需要客户端确认。

{ "type": "ka" }

订阅注册消息

客户端收到后connection_ack消息，客户端可以将订阅注册消息发送到Amazon AppSync. 此类型的消息是包含以下字段的字符串化 JSON 对象：

  • "id": <string>：订阅的 ID。此对于每个订阅都必须唯一，否则服务器将返回一个错误，指示订阅ID重复。

  • "type": "start"：常量 <string> 参数。

  • "payload": <Object>：包含与订阅相关的信息的对象。

    • "data": <string>：包含 GraphQL 查询和变量的字符串化 JSON 对象。

      • "query": <string>：GraphQL 操作。

      • "variables": <Object>：包含查询变量的对象。

    • "extensions": <Object>：包含授权对象的对象。

  • "authorization": <Object>：包含授权所需字段的对象。

订阅注册的授权对象

在基于 Amazon AppSync API 授权模式的标头参数格式部分中的相同规则适用于授权对象。唯一的例外是 IAM，此时 Sigv4 签名信息略有不同。有关详细信息，请参阅 IAM 示例。

使用 Amazon Cognito 用户池的示例：

{
  "id": "ee849ef0-cf23-4cb8-9fcb-152ae4fd1e69",
  "payload": {
    "data": "{\"query\":\"subscription onCreateMessage {\\n onCreateMessage {\\n __typename\\n message\\n }\\n }\",\"variables\":{}}",
      "extensions": {
        "authorization": {
          "Authorization": "eyEXAMPLEiJjbG5xb3A5eW5MK09QYXIrMTJEXAMPLEBieU5WNHhsQjhPVW9YMnM2WldvPSIsImFsZyI6IlEXAMPLEn0.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.CT-qTCtrYeboUJ4luRSTPXaNewNeEXAMPLE14C6sfg05tO0fOMpiUwj9k19gtNCCMqoSsjtQoUweFnH4JYa5EXAMPLEVxOyQEQ4G7jQrt5Ks6STn53vuseR3zRW9snWgwz7t3ZmQU-RWvW7yQU3sNQRLEXAMPLEcd0yufBiCYs3dfQxTTdvR1B6Wz6CD78lfNeKqfzzUn2beMoup2h6EXAMPLE4ow8cUPUPvG0DzRtHNMbWskjPanu7OuoZ8iFO_Eot9kTtAlVKYoNbWkZhkD8dxutyoU4RSH5JoLAnrGF5c8iKgv0B2dfEXAMPLEIihxaZVJ9w9w48S4EXAMPLEcA",
          "host": "example1234567890000.appsync-api.us-east-1.amazonaws.com"
         }
      }
  },
  "type": "start"
}

使用 IAM 的示例：

{
  "id": "eEXAMPLE-cf23-1234-5678-152EXAMPLE69",
  "payload": {
    "data": "{\"query\":\"subscription onCreateMessage {\\n onCreateMessage {\\n __typename\\n message\\n }\\n }\",\"variables\":{}}",
    "extensions": {
      "authorization": {
        "accept": "application/json, text/javascript",
        "content-type": "application/json; charset=UTF-8",
        "X-Amz-Security-Token": "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",
        "Authorization": "AWS4-HMAC-SHA256 Credential=XXXXXXXXXXXXXXXXXXXX/20200401/us-east-1/appsync/aws4_request, SignedHeaders=accept;content-encoding;content-type;host;x-amz-date;x-amz-security-token, Signature=b90131a61a7c4318e1c35ead5dbfdeb46339a7585bbdbeceeaff51f4022eb1fd",
        "content-encoding": "amz-1.0",
        "host": "example1234567890000.appsync-api.us-east-1.amazonaws.com",
        "x-amz-date": "20200401T001010Z"
      }
    }
  },
  "type": "start"
}

使用自定义域名的示例：

{
  "id": "key-cf23-4cb8-9fcb-152ae4fd1e69",
  "payload": {
    "data": "{\"query\":\"subscription onCreateMessage {\\n onCreateMessage {\\n __typename\\n message\\n }\\n }\",\"variables\":{}}",
      "extensions": {
        "authorization": {
          "x-api-key": "da2-12345678901234567890123456",
          "host": "api.example.com"
         }
      }
  },
  "type": "start"
}

SigV4 签名不需要/connect将附加到 URL，并使用 JSON 字符串化 GraphQL 操作替换data. 以下是 Sigv4 签名请求的示例：

{
  url: "https://example1234567890000.appsync-api.us-east-1.amazonaws.com/graphql",
  data: "{\"query\":\"subscription onCreateMessage {\\n onCreateMessage {\\n __typename\\n message\\n }\\n }\",\"variables\":{}}",
  method: "POST",
  headers: {
    "accept": "application/json, text/javascript",
    "content-encoding": "amz-1.0",
    "content-type": "application/json; charset=UTF-8",
  }
}

订阅确认消息

发送订阅开始消息后，客户端应等待Amazon AppSync发送了start_ack消息。这些区域有：start_ack消息会表明订阅成功。

订阅确认示例：

{
  "type": "start_ack",
  "id": "eEXAMPLE-cf23-1234-5678-152EXAMPLE69"
}

错误消息

如果连接启动或订阅注册失败，或者从服务器终止订阅，服务器将向客户端发送错误消息：

  • "type": "error"：常量 <string> 参数。

  • "id": <string>：对应已注册订阅的 ID（如果相关）。

  • "payload" <Object>：包含对应错误信息的对象。

示例：

{
  "type": "error",
  "payload": {
    "errors": [
      {
        "errorType": "LimitExceededError",
        "message": "Rate limit exceeded"
      }
    ]
  }
}

处理数据消息

当客户提交突变时，Amazon AppSync 识别所有对此感兴趣的订阅者并发送"type":"data"使用相应的订阅向每个人发送消息id来自 的"start"订阅操作。客户需要跟踪订阅id它发送的这样在收到数据消息时，客户端可以将其与对应的订阅匹配。

  • "type": "data"：常量 <string> 参数。

  • "id": <string>：对应已注册订阅的 ID。

  • "payload" <Object>：包含订阅信息的对象。

示例：

{
  "type": "data",
  "id": "ee849ef0-cf23-4cb8-9fcb-152ae4fd1e69",
  "payload": {
    "data": {
      "onCreateMessage": {
        "__typename": "Message",
        "message": "test"
      }
    }
  }
}

订阅取消注册消息

当应用程序希望停止侦听订阅事件时，客户端应发送带有以下字符串化 JSON 对象的消息：

  • "type": "stop"：常量 <string> 参数。

  • "id": <string>：要取消注册的订阅的 ID。

示例：

{
  "type":"stop",
  "id":"ee849ef0-cf23-4cb8-9fcb-152ae4fd1e69"
}

Amazon AppSync 使用以下字符串化 JSON 对象发回确认消息：

  • "type": "complete"：常量 <string> 参数。

  • "id": <string>：取消注册的订阅的 ID。

客户端收到确认消息后，它将不再收到有关此特定订阅的消息。

示例：

{
  "type":"complete",
  "id":"eEXAMPLE-cf23-1234-5678-152EXAMPLE69"
}

断开 WebSocket

在断开连接之前，为避免数据丢失，客户端应具有必要的逻辑，检查当前没有执行任何操作 WebSocket连接. 在断开连接之前，应先取消注册所有订阅 WebSocket.
